Rovix Motion
Rovix Motion
Our motors have long life, high efficiency and good stability. Insert the drive inside the motor to capture data more accurately.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Voltage (V) | No-Load | Rated | Stall | |||||||
| Range | Nominal | Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (mN.m) | Power (W) | Current (mA) | Torque (mN.m) | ||
| FF-N20VA | 05240 | 3.0~12.0 | 12 VDC | 16100 | 15 | 12240 | 60 | 0.3/3 | 0.37 | 210 | 1.2/12 |
| 08260 | 2.0~5.0 | 5 VDC | 14600 | 30 | 11800 | 110 | 0.26/2.6 | 0.31 | 470 | 1.3/13 | |
| FF-N20TA | 2818 | 0.8~1.5 | 12 VDC | 34000 | 70 | 31000 | 1140 | 0.2/2 | 0.64 | 6000 | 1.6/16 |
We are a factory specialize in producing motors more than 14 years, professional R&D team and mature management will bring you a pleasant experience. In order to confirm quality, from received material to shipment, every step is carefully checked. Quality is the basis of our development.
