Rovix Motion
Rovix Motion
| Ratio | 241k |
| Max. Rated Torque | 1.5~2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4~5 Kgf.cm |
| Gearbox Efficiency | 45%~60% |
| Gearmotor Model | Ratio | Rated Voltage | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (Kgf.cm) | Current (mA) | Torque (Kgf.cm) | |||
| GM2215FMN20-241K | 1:241 | 4.5 VDC | 43 / 58 / 68 | ≤ 50/65/75 | 34 / 50 / 56 | ≤ 120/130/140 | 25 / 28 / 30 | ≤ 350/680/750 | 0.15 / 0.18 / 0.2 |
| Model | Rated Voltage | No-Load RPM | No-Load mA | Rated RPM | Rated mA | Rated Torque (gf.cm) | Stall Current (mA) | Stall Torque (gf.cm) |
|---|---|---|---|---|---|---|---|---|
| SL-N20-04510500 | 4.5VDC | 10500 | ≤ 30 | 8250 | ≤ 80 | 2.0 | ≤ 300 | 10.5 |
| SL-N20-04514000 | 4.5VDC | 14000 | ≤ 40 | 12000 | ≤ 130 | 2.5 | ≤ 680 | 15.0 |
| SL-N20-04516500 | 4.5VDC | 16500 | ≤ 50 | 13500 | ≤ 160 | 2.5 | ≤ 750 | 18.0 |
We are a factory specialized in producing motors for more than 14 years. Our professional R&D team and mature management ensure a superior experience.
To guarantee excellence, every step from material reception to final shipment is carefully checked. Quality is the foundation of our development.
